Best DVB-T2 Tuner Receiver HD Converter Box HR-T24

  • Description:Best DVB-T2 Receiver,HD Converter Box,DVB T2 Tuner Mstar 7819+MXL603 tuner HD DVB-T2 Set Top Box Receiver & USB2.0 & PVR & HDMI +CI slot.
  • CPU:HD DVB-T2+ SB PVR Media Player+CI Slot
  • GPU:Tuner: NIM120 tuner
  • System:Chipset: MSTAR 7819 Mpeg transport stream and A/V decoding
  • RAM:Standard: DVB-T(ETSI EN 300 744)
  • ROM:Standard:DVB-T2(ETSI EN 302 755)
  • Interface:USB 2.0 port,single tuner Coaxial(RCAX1) ,YpbPr RCAX3; L/R audio RCAX2; CVBS; SCART (optional)
  • Email:9657@androidtvbox-factory.com
  • Detail

  • Contact Us

Best DVB-T2 Tuner Receiver HD Converter Box HR-T24
HD DVB-T2  Receiver & USB2.0 & PVR & HDMI +CI slot
(Best DVB-T2 Receiver,HD Converter Box,DVB T2 Tuner)

Mstar 7819+MXL603 tuner
Model NO.:HR-T24

MOQ:2000PCS

Best DVB-T2 Receiver

Best DVB-T2 Receiver Features:

1. Fully SD/HD DVB-T/T2,  SD/HD MPEG2 and  MPEG4 AVC H.264, support Full HD up to 1080P
2. With Common Interface for various CA modules (CI Slot)
3. Auto and manually scan all available TV and radio channels
4. Aspect ratio 16:9 and 4:3
5. HDMI, YUV, RCA, coaxial output
6. Multi-language menu and subtitle supported
7. Powerful and highly effective 7-day EPG function
8. Supports teletext
9. Parental lock
10.PVR, timeshift, software upgrade via USB 2.0
11.USB Multimedia playback supported
12.Easy to use and attractive menu

Best DVB-T2 Receiver Specifications:

1.Tuner: NIM120 tuner
2.RF input frequency: 44-1002Mhz
3.Bandwith: 6/7/8MHz
4.Input level: -83dBm
5.Signal input: IEC-type female
6.Chipset: MSTAR 7819
7.Mpeg transport stream and A/V decoding
8.Video standard: MPEG-4 AVC/H.264 HP@L4 SCART video model CVBS/RGB (for Europe,optional)
9.Aspect ratio: 4:3, 16:9
10.Video resolution: 576i, 576p, 720p and 1080i,1080P
11.Audio standard: ISO/IEC 14.496-3,AAC,AAC+,AC3

12.Audio mode: mono, dual-channel, stereo

Best DVB-T2 Receiver Multimedia format:

1.Picture: JPEG,BMP,PNG
2.Audio: MP3,WMA
3.Video: MKV,AVI,DIVX,XVID, MOV,VOB,FLV, 3GP,DAT,MPEG,MPG,MP4
4.Input Voltage:12V Adaptor
5.Power consumption:Real Standby <1watt
6.USB :for firmware upgrade, PVR and multimedia playback
7.Demodulation: QPSK, 16QAM, 64QAM, 256QAM
8.Code Rate: 1/2, 3/5,2/3, 3/4, 4/5, 5/6
9.Guard: from 1/128 to 1/4
10.FFT Mode: from 1K to 32K
11.Standard:
     DVB-T(ETSI EN 300 744)
     DVB-T2(ETSI EN 302 755)
12.Rear panel output:HDMI 576i, 576p, 720p and 1080i,1080P
13.Loop through output: IEC-type, connector, single tuner Coaxial(RCAX1); YpbPr RCAX3; L/R audio RCAX2; CVBS; SCART(optional)
14.Accessories:User Manual, Remote control, RCA Cable

15.Optional Accesssories:Scart Cable (optional),  Antenna (optional),  HDMI Cable(optional)

HD Converter Box Packing:

220mm metal case:
6 pcs/Carton;
Giftbox: 250*60*225MM; Carton Size: 375*260*235MM;
G.W: 6.3 Kgs;
N.W: 6 Kgs;
20": 5500PCS; 40": 11000 PCS;

40"HQ: 12,500PCS
