DVBT H.264 TV Converter Box Receiver HR-T66

  • Description:Xiyuntech Best DVB-T Box Receiver,TV Converter Box,DVB T Box,DVBT Box HR-T66, MOQ:3000PCS for iptv and ott tv operators.Welcome to contact us!
  • CPU:CPU Processor:550MHZ
  • GPU:Novatek 78316 DDR2 512Mb
  • System:Novatek 78316 MPEG4 H.264 HD DVB-T STB & Media Player & Coaxial & USB PVR & USB2.0 & HDMI & Scart or RCA & ANT IN/OUT
  • RAM:DDR2 512Mb
  • ROM:Flash: 32Mb
  • Interface:USB 2.0,HDMI, Scart, RCA, coaxial output
  • Email:9657@androidtvbox-factory.com
  • Detail

  • Contact Us

DVBT H.264 TV Converter Box Receiver HR-T66
(DVB-T Box Receiver,TV Converter Box,DVB T Box,DVBT Box)
Model Number:HR-T66
OEM&ODM Support
MOQ: 3000PCS

DVBT Box

In what color can make:Black
Front panel:Plastic
Solution:Novatek 78316
MPEG4 H.264 HD DVB-T STB & Media Player & Coaxial & USB PVR & USB2.0 & HDMI & Scart or RCA & ANT IN/OUT


DVBT Box Features:

1.Fully SD/HD DVB-T, SD/HD MPEG2 and  MPEG4 AVC H.264
2. Full HD,support up to 1080P
3.Auto and manually scan all available TV and radio channels
4.Aspect ratio 16:9 and 4:3
5.HDMI, Scart, RCA, coaxial output
6.Multi-language subtitle output supported
7.Powerful and highly effective 7-day EPG function
8.Supports teletext
9.Parental lock
10.PVR, timeshift  via USB 2.0
11.USB media playback and software upgrade via USB 2.0
12.Stores up to 1,000 programs
13.Accessories:Remote control, User Manual, RCA cable, Adaptor(5V), Warranty card
14.Optional Accesssories:HDMI Cable (optional, 1m, 1.2m, 1.5m, 1.8m)

DVBT Box Specifications:

1.Powerful Multimedia Features
   Photo: JPEG,BMP,PNG
   Audio: MP3,WMA
   Video: MKV、AVI、DIVX、XVID、MOV、VOB、FLV ,  DAT、MPEG、MPG、MP4 …
2.Tuner: Rafael R820T
3.IF input frequency: VHF: 174MHz - 230MHz/UHF: 474MHz - 866Mb
4.Bandwith: 7/8MHz
5.Input level: -83dBm
6.Signal input: IEC-type female
7.Chipset: Novatek 78316
8.CPU Processor: 550MHZ

DVBT Box Memory: DDR2 512Mb Flash: 32Mb
DVBT Box Channel Decoding

1.Standard: DVB-T
2.Demodulation: QPSK, 16QAM, 64QAM
3.FEC:1/2, 2/3, 3/4, 5/6, 7/8, automatic
4.Mode: 2K, 8K
5.Guard: 1/4,1/8,1/16,1/32
DVBT Box Demultiplexer
1.Standard ISO/IEC 13818-1; ARIB STB-B10
2.Input max. bit stream rate: 120Mbps (serial)/15MBps (parallel) Rear panel output
3.HDMI: 576i, 576p, 720p and 1080i,1080P
4.Loop through output: IEC-type, connector, single tuner,TV SCART, HDMI

DVBT Box Video Decoding

1.Standard:  MPEG-4 AVC/H.264 HP@L4
2.SCART video model CVBS/RGB (for Europe)
3.Aspect ratio: 4:3, 16:9
4.Video resolution: 576i, 576p, 720p and 1080i, 1080P

DVBT Box Audio Decoding

1.Standard: ISO/IEC 14.496-3
2.Audio mode: mono, dual-channel, stereo
1.Input Voltage: 5V Adaptor
2.Power consumption:8W(max), Real Standby <1watt

DVBT Box Package List:

Giftbox: 55 x 175 x 185 MM
Carton Box: 210 x295 x370MM ( 10 PCS/CTN)
GW: 6.00/6.50KGS
20"": 12,500PCS
40"": 25,000PCS
40""HQ: 30,400 PCS
