FTA Digital Set Top Box DVB-C HD Mstar Satellite Receiver for Netherlands

  • Description:MOQ:2000 PCS FTA satellite recceiver is made of MPEG4 DVB-C,Set Top Box DVB-C|DVB-C HD tuner.This tv mpeg4 box hot selling for Netherlands&Poland IPTV Telecommunication operators.
  • CPU:HD MPEG4 FTA DVB-C FTA MPEG4 H.264 HD DVB-C Set Top Box Receiver & Scarts & Coaxial & CVBS & USB2.0 & PVR & HDMI
  • GPU:Mstar solution
  • System:Mstar7801+ MXL603 TV Tuner
  • RAM:DDR2 512M
  • ROM:32Mb
  • Interface:Scarts & Coaxial & CVBS & USB2.0 & PVR & HDMI
  • Email:9657@androidtvbox-factory.com
  • Detail

  • Contact Us

FTA Digital Set Top Box DVB-C HD Mstar Satellite Receiver for Netherlands &Poland &Germany TV Operators
Model number:HR-C61
Solution:Mstar7801+ MXL603 TV Tuner

120mm Plastic Case

MOQ:2000 PCS

Set Top Box DVB-C


DVB-C-Set-Top-Box Features:

In wSet Top Box DVB-Chat color can make:Black/white/silver
Front panel:Case 220/180*160*38mm
1.Fully SD/HD DVB-C compliant,support full HD 1080p
2.Support USB personal video recording (PVR),Timeshift and PPV
3.Support MPEG4 SP & ASP, H.263 P3, DivX Home Theater Profile, JPEG up to 1080P, decodes MP1/2/3, AC3, AAC-LC, HE-AAC audio streams
4.Various USB Hard Disk / Flash memory supported up to 1TB (1000GB),USB media player function  5.Support FAT32,EXT3 and NTFS file system
6.Watch & record the current channel
7.Scheduled recording via EPG, wakeup automatically & record
8.Fast forward & rewind playback (x2, x4, x8,x16, x32)
9.Decoding H.264 HD HP@L4.1 and MPEG-2 HD MP@HL, MPEG-2 SD MP@ML
10.Multi-language list OSD supported
11.Easy and fast software upgrade through USB port
12.Support Auto/NTSC/PAL and 4:3 16:9 wide screen
13.Full-Function IR remote control as well as front panel buttons
14.Parental lock function and 5 Favorite channel groups
15.Channel search in automatic, manual and network search

Set Top Box DVB-C Specification:

Media files playback as below:
1.Music: MP3,WMA
2.Photo: JPEG,BMP,PNG

Set Top Box DVB-CTuner and Demodulation parameter:

1.RF input frequency:  44MHz~862MHz
2.bandwidth:6/8MHz
3.Demodulation: 16,32,64 , 128,256 QAM
4.Symbol rate: 0.7 ~ 7Mbaud
5.Input impedance:75Ω
6.RF IN connector type: F-type
7.Input and Output: USB, HDMI, Coaxial, CVBS, L/R AUDIO, SCART(YUV), ANT IN, ANT OUT, DC IN
8.Power Consumption: 8W
9.Power Voltage: 100~240V
10.Adaptor Voltage: 5V
11.Power Cord Length: 1M "
12. Accessories User Manual,  Remote control,  RCA Cable, Power adapter
13.ptional Accesssories Scart Cable (optional),  Antenna (optional),  HDMI Cable (optional)

Set Top Box DVB-C 120mm metal case:

1.Giftbox:160 x 55 x 170 MM
2.Carton Box : 355 x295 x335MM ( 20 PCS/CTN)
3.NW/GW: 7.6/8.1KGS
4.20"": 16,520PCS
5.40"": 33,040PCS
6.40""HQ: 37,040PCS"
